| Model: | GJD-600 | Type: | Desorption Electrolysis System |
|---|---|---|---|
| Desorption Solution: | PH > 13.5 | Time of Application: | Infinite |
| Electrolysis Star: | 100-110°C | Electrolytic Tank: | 0.45-0.52MPa |
| Gold Loaded Carbon Content: | ≥3.5kg/t | ||
| برجسته: | construction mining equipment,mining safety equipment |
||
Desorption Electrolysis System with 300~500 t/d scale and 3.5kg/t gold loaded
Specification:
| Model | GJD-600 | |
|
Suitable Scale |
Mine Scale (t/d) | 300~500 |
| Raw Ore Grade (g/t) | 2~8 | |
|
Operation Parameters |
Desorption Solution: | PH > 13.5 |
| Time of Application: | Infinite | |
| Electrolysis Start: | 100-110°C | |
| Electrolysis Ending: | 150°C | |
| Electrolysis Current: | 350-1250A | |
| Electrolysis Pressure: | 2-4V | |
| Upper of Desorption Column: | 0.50-0.57MPa | |
| Electrolytic Tank: | 0.45-0.52MPa | |
| Gold Loaded Carbon Content |
≥3.5kg/t
|
|
Description:
Desorption electrolysis system obtains gold mud from carbon by desorption and electrowinning.
1.In the high temperature (150℃) and pressure (0.5MPa), the desorption rate reaches 98%
2.Since desorption and electrolysis does not require different temperatures, it is not necessary to change temperature.
3.The quickness and efficiency of machine dramatically diminishes gross electricity consumption by 1/2-1/4.
4.Desorption does not require sodium cyanide, which reduces cost and averts pollution.
In gold electrowinning process,when the electrolysis equipment is added with anions which are more easily absorbed by activated carbons, Au(CN)2ˉ is replaced by anion and the gold desorption is achieved. After the carbons loaded with gold are desorbed, pregnant solution is process via ionization. At last, solid gold is attained.
