Model: | SD13S | Engine: | Shangchai SC8D143G2B1 |
---|---|---|---|
Operating weight (Ripper not included): | 14.9t | Rated power: | 63kw |
Blade type: | Straight tilt blade | Ground length and ground pressure: | 2365-0.044kpa |
برجسته: | shantui construction machinery,dozer construction equipment |
Shantui bulldozer SD13S equipped with Shangchai SC8D143G2B1 engine
Specification:
ITEM | SD13S | Engine | Shangchai SC8D143G2B1 |
L×W×H (Ripper not included) | 4492×3450×3000mm | Ripping depth of ripper | - |
Operating weight (Ripper not included) | 14.9t | - | |
Rated power | 63kw | Lifting height of ripper | - |
Grade ability | 30 | Number of carriers (each side) | 2 |
Blade type | Straight tilt blade | Number of track rollers (each side) | 6 |
Blade width | 3450×980mm | Number of track shoes (each side) | 38 |
Width of track shoe | 700mm | ||
Track gauge | 1880mm | ||
Ground length and ground pressure | 2365-0.044kpa | ||
Dozing capacity | 3.3m3 | Pitch | 190mm |
Forward speed | 0-3.2 | ||
0-5.9 | |||
0-9.8 | |||
Max drop below ground of blade | 590mm | Reverse speed | 0-3.9 |
Lift height of blade | 930mm | 0-7.1 | |
Ripper type | - | 0-11.9 |
Description:
The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation;
Advantage:
1. The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;
2. The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;
3. The single control lever can control all blade actions;
4. The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;
